The Arc Grid Wood MDF-on-PET Acoustic Wall Panel translates large intersecting circular arcs routed through a compact rectangular wood-toned MDF composition into a practical decorative acoustic wall system. Its key visual result is a calm graphic of overlapping circles that breaks from rectilinear acoustic panel conventions. Instead of relying on a printed surface to create the pattern, the foreground is formed from real MDF components machined by CNC equipment, while the polyester fiber substrate remains visible in the negative spaces. This two-layer relationship gives the wall depth, shadow and material contrast while retaining the acoustic function of the PET backing. This model is best understood as a CNC-defined decorative system rather than a fixed stock tile. Its value comes from the relationship between the cut MDF geometry, the visible polyester fiber background and the way modules are coordinated across a project wall.
• Pattern identity: the Arc Grid Wood geometry is immediately distinguishable from standard straight-slat acoustic panels and can be used as a project-specific visual signature.
• CNC repeatability: arc radius, line position, rectangular module size and multi-panel continuation can be adjusted in the CAD path and then reproduced consistently for batch manufacturing.
• Layered appearance: the MDF decorative face creates the foreground, while exposed polyester fiber becomes an intentional background rather than a hidden substrate.
• Dimension flexibility: finished size is determined by the pattern and wall design instead of one fixed stock format, making the series suitable for square, tall, rectangular and irregular modules.
• B2B project workflow: drawings, sample approval, pattern direction and module numbering can be confirmed before bulk production to reduce installation ambiguity.
Production begins with confirmation of the vector/CAD geometry, followed by CNC machining of the MDF decorative layer. The process allows curved, angled and irregular components to be repeated without relying on hand cutting. The finished composition is assembled with the PET acoustic substrate so the exposed background becomes part of the design.
For the Arc Grid Wood MDF-on-PET Acoustic Wall Panel, the manufacturing review should focus specifically on arc radius, line position, rectangular module size and multi-panel continuation. These are the variables most likely to change the visual character of this model. Where narrow bridges, small corners or pointed components occur, the drawing should be checked for practical CNC machining and handling before a production quantity is released.
|
Product Name |
Arc Grid Wood MDF-on-PET Acoustic Wall Panel |
|
Core Keyword |
Arc Grid Wood |
|
Construction |
Polyester fiber acoustic substrate + CNC-machined MDF decorative layer |
|
PET Substrate Thickness |
5 mm / 9 mm standard |
|
MDF Thickness |
9 mm standard; other thicknesses customizable |
|
Reference Format |
400 × 700 mm reference module |
|
Finished Size |
Customized according to confirmed pattern drawing and project dimensions |
|
Pattern Process |
Professional CNC engraving / routing / cutting based on designer-approved path |
|
Geometry Options |
Project adjustments may include arc radius, line position, rectangular module size and multi-panel continuation |
|
MOQ |
400 pieces per design/model |
|
Project Documentation |
CAD/vector file or approved shop drawing recommended before mass production |
|
Performance Data |
Use verified acoustic/fire/environmental certificates where the project specification requires numerical values |
The Arc Grid Wood MDF-on-PET Acoustic Wall Panel is suited to small meeting rooms, consultation rooms, cafe niches, hotel guestrooms and compact reception walls. The design can be used as a full-wall repeat, a framed acoustic insert or a localized feature panel. Where the pattern is directional, the installation drawing should mark the orientation of every module. This avoids accidental reversals and keeps visual lines continuous across seams.
The most important planning point for this model is the arc grid wood rhythm. Designers should decide whether the pattern will repeat identically, mirror around a centerline, rotate between modules or terminate as an irregular feature. That decision should be reflected in the shop drawing so the final wall looks intentional rather than assembled from unrelated panels.
The 400 × 700 mm reference format makes the Arc Grid Wood model practical for narrow wall bays. A pair or trio of panels can be aligned so the circular arcs continue from module to module, creating a larger geometric drawing behind a small meeting table without overwhelming the room.
This scenario is a design recommendation rather than a claim of a completed SHIPO project. For website publication, it can later be replaced by a verified customer case, installation photograph, country/market information and measurable project data when those materials are available.
The Arc Grid Wood MDF-on-PET Acoustic Wall Panel can be developed from a standard reference pattern or adapted around project requirements. The primary customization variables for this design are arc radius, line position, rectangular module size and multi-panel continuation. Standard polyester fiber substrate thicknesses are 5 mm and 9 mm, while the MDF decorative layer is normally 9 mm and can be produced in other thicknesses when required. Finished panel dimensions are not restricted to the reference drawing: SHIPO can review wall dimensions, required module divisions and pattern terminations before confirming the production file. As a China acoustic panel Supplier, Factory and Manufacturer, SHIPO is positioned for bulk B2B orders, with a minimum order quantity of 400 pieces per design.
• Send the wall elevation, target finished size and preferred product reference.
• Confirm the Arc Grid Wood pattern scale and the project-specific variables: arc radius, line position, rectangular module size and multi-panel continuation.
• Confirm PET substrate thickness (5 or 9 mm), MDF thickness (9 mm standard or custom) and the approved MDF surface/finish sample.
• Approve the CAD/shop drawing and, when necessary, one physical sample before batch manufacturing.
• For directional or multi-module designs, use panel numbers and orientation marks to support site installation.
Yes. The arcs can be designed as one larger composition and then divided into production modules. Panel numbering is important for installation.
Yes. This reference size is pattern-specific, not a fixed limitation. The arc geometry can be recalculated for another width or height.
Yes. The CNC route can follow concentric, offset or partially overlapping arc concepts, subject to final drawing approval.
Contact SHIPO for samples, drawing review, size customization or a bulk quotation for the Arc Grid Wood MDF-on-PET Acoustic Wall Panel. To receive an accurate proposal, send the target wall dimensions, required quantity, PET substrate thickness, MDF thickness, preferred finish, and any CAD/vector pattern file available. SHIPO can then evaluate the Arc Grid Wood geometry, confirm manufacturable details and prepare the production solution for orders from 400 pieces per design.
